Size | PR | TT/TL | Load Index | Speed Rating | Standard Rim | T.D (mm) | Pressure | QTY PCS/40HQ | |
KPA | PSI | ||||||||
11R22.5 | 16 | TL | 146/143 | M | 8.25 | 21.0 | 830 | 120 | 276 |
12R22.5 | 18 | TL | 152/149 | M | 9.00 | 20.0 | 930 | 135 | 240 |
215/75R17.5 | 18 | TL | 135/133 | J | 6.00 | 17.0 | 860 | 125 | 600 |
225/70R19.5 | 14 | TL | 128/126 | M | 6.75 | 15.0 | 760 | 110 | 522 |
235/75R17.5 | 18 | TL | 143/141 | J | 6.75 | 170 | 900 | 130 | 530 |
245/70R19.5 | 16 | TL | 136/134 | M | 7.50 | 15.0 | 825 | 120 | 454 |
265/70R19.5 | 16 | TL | 140/138 | M | 7.50 | 15.0 | 775 | 112 | 430 |
275/80R22.5 | 16 | TL | 149/146 | M | 8.25 | 19.0 | 850 | 123 | 280 |
285/70R19.5 | 18 | TL | 150/148 | J | 8.25 | 16.0 | 900 | 130 | 380 |
295/80R22.5 | 18 | TL | 152/149 | M | 9.00 | 22.0 | 900 | 130 | 254 |
295/80R22.5-1N | 18 | TL | 152/149 | M | 9.00 | 21.0 | 900 | 130 | 258 |
315/70R22.5 | 18 | TL | 152/148 | M | 9.00 | 21.0 | 830 | 120 | 246 |
315/80R22.5 | 20 | TL | 156/150 | M | 9.00 | 21.0 | 850 | 123 | 240 |
▲ With special pattern name WVK78.
1N：Adding one layer of nylon wrapper can effectively enhance the strength of the bead and improve the Anti-load performance.
2N：Adding double-layer nylon wrapper greatly enhances the strength of the bead and improves the anti-load performance.
